Metal Point Boltless Shelving

Commodity name： Metal Point Boltless Shelving
Summary： Combined structure, easy to disassemble, light to move
Load： 100kg~800kg per layer, can be customised according to requirements
Material： Q235/Q345
Material Thickness： 0.6mm~1.0mm

Boltless Shelving price: telephone contact or online consultation Boltless Shelving contact number: +86-15861699908

Service Hotline:

86-15861699908

Get Quote

Related Products

Products
Shelf Video
General Parameters
FAQ
Shelf Case

Metal Point Boltless Shelving

Boltless Shelving are mainly composed of columns, beams, and steel laminates, and the beams are assembled by hanging the columns. It is divided into light shelf or medium-sized shelf, with a load capacity of 50kg-800kg per layer, fully combined structure, flexible combination, easy loading and unloading, and the spacing between layers can be adjusted arbitrarily according to the height of the cargo space in terms of the unit of laminate. It is suitable for manual access to the lighter scattered items, widely used in electronics, medicine, food, supermarkets, archives industry.

Product Details

Product Features

Medium Racking

1.Fully assembled structure, random combination, easy and flexible installation and disassembly;

2.Steel laminate adopts cold rail steel plate as raw material, the shelves can be adjusted and combined at will, and the layer height can be adjusted at will;

3.High-strength bolt connection, firm and stable;

4.Epoxy tree spraying, simple structure, beautiful appearance;

5.Shelf material cross-section optimisation, a variety of tubing options to improve the load-bearing capacity;

6.New height appropriate, convenient manual access to the goods, is the mall supermarkets, corporate warehouses ideal storage products.

Light Duty Racking

1.Combined structure, easy to disassemble, light to move;

2.Welding solid type column piece, crossbeam and column hook and loop connection;

3.Steel laminates are placed on the crossbeam step mouth, the height of the crossbeam is adjustable every 60mm.

4.Steel laminate bottom surface touch welding longitudinal reinforcement, plate surface is solid, strong bearing capacity.

Carrying capacity	100kg~800kg/layer, can be customised on request
Product Classification	Light duty racking, medium duty racking
Pickup method	Human access
Product Colour	Orange, blue, white, customisable
Access requirements	Customised to customer requirements
Warehouse requirements	The ground level should be good
Scope of application	Workshops, warehouses, libraries and other places to use. However, it is possible to increase the length of a single set of shelves to store more things, but still keep them within the load capacity.
Product Advantage	Simple structure, large bearing capacity, easy to dismantle, economical, layer height can be adjusted arbitrarily
Framework	Composed of column pieces, beams, laminates, safety pins, snap assembly

F：What are the terms of your deal?

Q：1.Payment terms: T/T 30% deposit upon order confirmation, 70% balance upon bill of lading. Or L/C.

2.Delivery time: normally within 30 days of receipt of deposit.

3.Sample Policy: Samples are always available for each model. Samples can be ready within 7-15 days after payment is received.

4.Port of shipment: Shanghai, China.

5.Discounts: We offer discounts for large quantities.

F：How do I deliver my goods?

Q：1.Sea freight: Once we know the seaport where you will deliver the goods, we will update the sea freight charges.

2.Customer Nominated Agent: Please let us know the contact information of your shipping agent and we will arrange for delivery of the items.

F：What are your services?

Q：1.We will respond to your inquiry about our products or prices within 24 hours.

2.Trained and experienced staff answer all your inquiries in fluent English.

3.OEM and ODM, any of your customized racks we can help you design your products.

4.We have experienced and professional engineers to provide the best solution.

F：How can I buy your products?

Q：Design drawing→Confirm drawing→Quotation→PI→Confirm PI→Arrange 30% deposit→Manufacturer→QC inspection→Payment of balance→Delivery

F：What are your strengths

Q：1.Warranty: one year warranty, damaged parts will be replaced and sent to you.

2.FACTORY PRICE: Factory direct competitive price.
